KAI-PU KP227 New Stationary 227KW Four Stroke Six Cylinder Water Cooled Diesel Engine Generator Set

Share to:

Model:
KP227
Brand:
KAI-PU
Aspiration:
Turbocharged
Rated Power:
227kw
Rated Speed:
1500/1800rpm
Bore*Stroke:
135*150mm
Displacement:
12.8L
Fuel Consumption:
206g/kw.h
Noise:
≤117dB
Smoke:
≤3.0FSN
Color:
Customers' Requirement

Availability:


Inquire

Features

KAI-PU series diesel engine is a new type of power generation diesel engine which is improved on the basis of the original series 135 series.

The air intake system is optimized in structure, the appearance of pipeline is simplified, and high-grade vehicle paint is selected. The appearance is more compact and beautiful.

Equipped with oil and water separator, system alarm self-protection device and oil pump, making the diesel engine application more safe, reliable and convenient.

Adopting high pressure and air medium cooling technology, equipped with special high pressure oil pump, porous low pressure inertia injector and electronic governor, it can atomize well and burn well , reduce noise and save energy and environmental protection.

Product Details

KP206-KP350jubu2 KP206-350jubu1

6135AZD-1-KP206beimian KP425-KP475局部4

Four-stroke 6 cylinder diesel engine Brand Generator Set Use Diesel Engine New 4 Stroke diesel engines High Performance Four-stroke Six CylinderDiesel Engines Brand New Stationary Electric Staring diesel engines New Stationary Electric Staring Machinery diesel engines 227kw Four Stroke 6 cylinder diesel engine 227kw Four Stroke Water Cooled Diesel Engine Generator Set Four-stroke Six CylinderDiesel Engines 227KW Four Stroke Six Cylinder Water Cooled Diesel Engine

Engine Model	KP227
Type	In-line, Direct injection, four-stroke, water-cooled
Intake Type	Turbocharged
Max power	227kw
*BoreStroke**	135*150(mm)
Number of Cylinders	6
Cylinders Type	Wet liner
Total Displacement	12.8（L）
Specific Fuel Consumption	206（g/kw.h）
Specific Oil Consumption	≤1（g/kw.h）
Idle Speed	500(rpm)
Rated Speed	1500/1800(rpm)
Speed Governing Mode	Electronic governor
Starting Mode	Electrical starting
Crankshaft Rotating Direction	Anti-Clockwise / Facing the flywheel
Noise	117(db)
Smoke	≤3.0
Flywheel casing	SAE 1#
Flywheel	SAE 14#
Net Weight	1160(kg)
*Longwidehigh*	14557951245(mm)
Fuel Grade(According to the Provisions of GB 252)	General Environment No.0 or No.-10 Light Diesel Oil
Southern Area	No.10 Light Diesel Oil
Northern Cold Area	No.-35 or Lower Point Light Diesel Oil
Engine Oil According to The Provisions of GB 11122	CF15W/40(Below environment temperature-5℃)

Engine Model	KP227
Type	In-line, Direct injection, four-stroke, water-cooled
Intake Type	Turbocharged
Max power	227kw
*BoreStroke**	135*150(mm)
Number of Cylinders	6
Cylinders Type	Wet liner
Total Displacement	12.8（L）
Specific Fuel Consumption	206（g/kw.h）
Specific Oil Consumption	≤1（g/kw.h）
Idle Speed	500(rpm)
Rated Speed	1500/1800(rpm)
Speed Governing Mode	Electronic governor
Starting Mode	Electrical starting
Crankshaft Rotating Direction	Anti-Clockwise / Facing the flywheel
Noise	117(db)
Smoke	≤3.0
Flywheel casing	SAE 1#
Flywheel	SAE 14#
Net Weight	1160(kg)
*Longwidehigh*	14557951245(mm)
Fuel Grade(According to the Provisions of GB 252)	General Environment No.0 or No.-10 Light Diesel Oil
Southern Area	No.10 Light Diesel Oil
Northern Cold Area	No.-35 or Lower Point Light Diesel Oil
Engine Oil According to The Provisions of GB 11122	CF15W/40(Below environment temperature-5℃)

Model	A	B	C	D
KP227	995	200	438	610

Model	A	B	C	D
KP227	995	200	438	610
